Double Reduced Cold-Rolled Tinplate Steel Coil

Email：manager@fgalloysteel.com

Phone：+86 15763569125

WeChat：+86 15763569125

WhatsApp：+86 15763569125

Inquiry Now →

OVERVIEW

Definition of secondary cold-rolled tin-plated steel coil

Secondary cold-rolled tin-plated steel coil (DR material tin-plated steel coil for short) is a high-end plate that is tin-plated after secondary cold-rolling of the cold-rolled substrate. It has higher strength and thinner thickness characteristics, and mainly meets the fields of food and beverage cans, chemical tanks, etc., which have strict requirements on material lightweight and corrosion resistance. Its processing technology can significantly improve the hardness and surface finish of the material. At present, it has achieved stable growth in sales in the domestic and foreign markets, and the user group continues to expand.

Product Parameters

Product Name	Double Reduced Cold-Rolled Tinplate Coil
Thickness	0.18mm-0.50mm
Width	260mm-980mm
Length	Support customization
Tin Coating	General: 2.8g or 5.6g, can be produced according to your needs
Substrate Type	MR / SPCC / L / D
Reference Standard	GB/T 2520, JIS G3303, JIS G3315, DIN EN 10202, DIN EN 10203

Surface State of Tinplate

Surface State	Features
Light Surface	Electroplated tin smooth raw material strip after melting treatment to obtain the glaze,Smooth surface with very fine grindstone pattern
Stonetextured Surface	Electroplating tin raw material with the glaze obtained after melting treatment,Grindstone pattern with certain direction
Silvercolor Surface	Electroplating tin raw material with the glazed surface obtained after melting treatment, the surface is rough and dull
Mattless Surface	The surface of the substrate is rough and dull, and the tin plating layer is not soft melting

Substrate Type

Substrate Type	Introduction
MR	The most general steel, steelmaking impurity residue less, excellent mechanical properties and corrosion resistance
L	Used for the production of acidic contents (oranges, yellow peaches, pineapples, etc.), and the inner surface of the food cans for iron high corrosion resistance tinplate substrate steel, such tinplate is often calledKPlate
D	Used to produce two pieces of high-processing tin plate substrate steel, such tin plate is often called.DIMaterial
SPCC	Chinese characteristics, using ordinary hot rollingSPHCProduces, usually used for miscellaneous tank purposes.

Coating Weight

Classification	Representation of Tin Coating Weight	Tin Plating Nominal Weight (g/m2)	Minimum Average Tin Plating Weight (g/m2)
Equal Tin Plating (E)	1.1/1.1	1.1/1.1	1.8
	2.2/2.2	2.2/2.2	4.0
	2.8/2.8	2.8/2.8	5.0
	5.6/5.6	5.6/5.6	10.5
Differentiated Tin Plating (D/A)	2.2/1.1	2.2/1.1	2.0/0.9
	2.8/1.1	2.8/1.1	2.25/0.9
	5.6/1.1	5.6/1.1	5.05/0.9
	2.8/2.2	2.8/2.2	2.25/2.0
	5.6/2.2	5.6/2.2	5.05/2.0
	5.6/2.8	5.6/2.8	5.05/2.25

Chemical Composition

No.	C	Si	Mn	S	P	Cu	Ni	Cr	Mo
D	0.12	0.03	0.6	0.05	0.02	0.2	0.15	0.1	0.05
L	0.13	0.03	0.6	0.05	0.15	0.03	0.04	0.06	0.05
MR	0.13	0.03	0.6	0.05	0.2	0.2	0.2	0.1	0.05

Mechanical Properties & Applications

Standard Name	Nominal Hardness HR30TS	Strong Yield MPA	Scope of Application
T-1	49	230 /-50	Drawing requirements, drawn ironing cans, nozzles, nozzles, closures
T-2	53	245 /-50	Ring and plug, dome, closure, shallow pull and special tank parts
T-2.5	55	260 /-50	Battery cell, small can cover and body
T-3	57	275 /-50	Cans and cans, large diameter caps, crown caps
T-3.5	59	290 /-50	Can body, closure and crown lid
T-4	61	340 /-50	Can body, closure and crown lid
T-5	65	480 /-50	Cans and cans

Main grades and performance indicators

Secondary cold-rolled tin-plated steel coil covers DR7M~DR10 grades, and the implementation standards include Q/BQB450-2009, JIS G3303:2008, etc. The tempering hardness range corresponds to Rockwell hardness (HR30T) 54-68, which is suitable for large can bodies, high-pressure containers and other scenes34. Its thickness tolerance is controlled within 8.5%, and the width tolerance is 0~1.5mm. The hardness uniformity is ensured by continuous annealing (CAPL) process.

Specification range and surface treatment

Thickness: 0.18~0.55mm (T-3 to T-5 grades), special specifications can be supplied by agreement.

Width: 700~1200mm, length 500~1168mm, inner diameter of the coil can be customized according to customer needs.

Surface state: divided into three categories: bright (B), rough (R), and silver (S), with a roughness range of 0.13~0.59μm, meeting the requirements of different canning processes for formability

Industry development trend of secondary cold-rolled tinplate coils

With the increasing demand for lightweight and material strength in the food, beverage, and chemical packaging industries, secondary cold-rolled tinplate has become an important direction to replace traditional primary cold-rolled tinplate with its advantages of thinning and consumption reduction.
