The application of cold-rolled non-oriented silicon steel in the field of magnetic switches is mainly based on its excellent electromagnetic properties.

Product Parameters

Material properties and applicability

1. Low iron loss and high magnetic permeability

The material optimizes the grain structure through deformation and recrystallization annealing. The hysteresis loss (Ph) and eddy current loss (Pe) are significantly lower than those of ordinary steel, which is particularly suitable for switch scenarios that require frequent magnetization/demagnetization.

Typical grades (such as 50W600, 35W400) have a silicon content of 2.9%-3.4% and an extremely low carbon content (≤0.08%), ensuring high resistivity to reduce eddy current losses.

2. Magnetic property uniformity

The grain structure of non-oriented silicon steel is isotropic, and the magnetic properties are consistent in different directions, which is suitable for manufacturing switch components with complex shapes.

3. Thickness and processing flexibility

Common thickness is 0.05-1mm (especially 0.35mm, 0.5mm), and switch parts can be customized through punching, cutting and other processes

Recommended grades and parameters

50W600, 0.5 mm: Low iron loss, balanced magnetic induction, used for high-frequency magnetic switches, relays |

35W400, 0.35 mm: High magnetic permeability, excellent energy efficiency, used for precision solenoid valves, small switches

50WW800, 0.5 mm: Cost optimization, strong versatility, used for industrial-grade electromagnetic switches
